Product Characteristics
Unparalleled Durability and Safety Features
Constructed with precision, the carbon steel body offers exceptional strength and resistance to wear, corrosion, and environmental stressors. The 3-axle configuration distributes weight evenly, reducing strain on individual axles and enhancing stability. Furthermore, it incorporates advanced safety features such as reinforced tank walls, secure locking systems, and anti-skid surfaces to ensure safe handling of transported materials, making it a trusted choice for industries handling sensitive or high-risk cargo.
Efficient and Cost-Effective Design
The 3 Axle Carbon Steel Tank Semi-trailer offers optimal capacity for large-scale liquid transport, allowing businesses to maximize payload while minimizing trips. Its aerodynamic tank design contributes to reduced drag and better fuel efficiency, lowering operational costs over time. Additionally, its compatibility with industry-standard coupling systems ensures easy integration into existing fleets.
Product Parameters
| Size | 10500mm*2500mm*3700mm |
| Volume | 30-60m³ |
| Tank body | Q235A/4-5mm steel sheet (Stainless steel/aluminium alloy optional) |
| End plate | Q235A/6mm .ball shape (Stainless steel/aluminium alloy optional) |
| Axle | 3 axle LuyueQiao brand 13T (Optional) |
| Suspension | Mechanical suspension American type (Optional) |
| Leaf spring | Leaf spring 10pcs*90*13mm (Optional) |
| Manhole cover | 500mm manhole cover with breath valve .2 sets (Optional) |
| Tire | 12R22.5 12pcs (Brand and specs optional) |
| Wheel rim | 9.0-22.5 12pcs (Brand and specs optional) |
| Discharge valve | 4″disc valve |
| Discharge pipe | 4″seamless steel tube |
| Bottom valve | 1 set |
| Kingpin | 2″/3.5″ bolt-in /welded king pin |
| Landing gear | Two-speed, manual operating ,heavy duty landing gear 28T |
| Compartment | Single (Optional) |
| Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
| ABS | Optional |
| Light | LED 8 side lights and 2 rear lights 2 width lamp |
Detail
Why choose our Carbon Steel Tank Semi-trailer？
Upgrade your transportation capabilities with the 3 Axle Carbon Steel Tank Semi-trailer—crafted for durability, efficiency, and versatility. Whether you operate in agriculture, petroleum, or chemicals, this semi-trailer delivers a solution you can depend on for your liquid cargo needs.
Low tare, high revenue. The alloy shell trims 1.5-2 t versus steel, freeing room for an extra 1 900 L of diesel per trip and improving fleet mpg by 5-8 %.
Corrosion-proof longevity. Anodised inner walls plus phenolic epoxy lining shrug off sulfur and bio-fuel blends, extending shell life by a.
Rapid, spill-free unloading. API bottom-loading adapters, Kamlok quick couplings, and EMCO Wheaton optic probes drain a full load in under 25 min while guarding against overfill.
